- No Bottle No Rinsing, No Bottle No Filling & No Bottle No Capping.
- Bottle Holding & Transfer with neck holding Systems.
- Capper to adjust torque setting arrangement is provide to avoided Leakage.
- Temperature gauge mounted on tank to indicate liquid temperature.
- No Change over Parts for any size bottle upto 2000ML.
- AC Variable Speed Frequency drive.
- All Rubber Parts are manufactured Food Grade silicon Waiton material with 100 shores harder.
- Control Panel is provided with 3HP AC Drive with liquid level controller with Emergency switch.
- No change over setting is required to increase / Decrease the speed of the machine provided on finger inside the filling Tank conical header is avoid pulp storage in filling Tank.
Rinser
Filler
Capper
Maximum Speed
Main Body
Housing
Main Tank
Liquid Contact Parts
In feed Air Conveyor
Out feed Conveyor
Hopper for Cap Feeding
Main Motor
Gear Box
20 Head
24 Head
10 Head
110-120 BPM for 300 ML
MS Fabrication with SS Gladding
SS 304
Jacket Head Type Systems
SS 316
12 Feet Long SS 1 HP Blower
24 Feet Long SS 0.5HP Geared Motor Mounted with slate belt
0.5 HP Geared Motor
3 HP 1000 RPM make Hindustan/Crompton
W110 Ratio 50:1 make bonfiglioli Italy
